Picture of ISCAR FFQ4 D5.0-10-1.50-12 Milling Cutter 5.000 Diameter Face Mill 1.500 2.000 OAL 10 Flute

ISCAR FFQ4 D5.0-10-1.50-12 Milling Cutter 5.000 Diameter Face Mill 1.500 2.000 OAL 10 Flute

ANSI: FFQ4 D5.0-10-1.50-12

ISO: FFQ4 D5.0-10-1.50-12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3332988
Delivery date: 3-5 days
$1,334.40

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Feed Milling, Ramp Milling, Copy Milling, Face Milling, Slot Milling
Shipping State Texas
Package Size 1
Insert Application General Purpose
Made In USA No
Insert Type Positive
Insert/Tool Tool
Dimensional Specifications
Cut Dia Min 4.1100 104.39MM
Insert Size Ic 12
Machine Side Connection Size 1.5000 38.10MM
Machine Side Connection Type Face Mill/Shell Mill
Overall Len 2.0000 50.80MM
Depth Of Cut Max 0.0240
Flutes/Inserts 10
Cutter Dia 5.0000 127.00MM
Cut Dia Max 5.0000 127.00MM
Tool Material Steel
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Square
Cool Sply Type Through Hole
Insert Style FF
Fasteners & Connectors
Insert Screw 3348063
