Picture of ISCAR FF EW D1.5-2.5-CF4-09-C Milling Cutter 1.500 Diameter Clickfit 1.574 4.470 OAL 3 Flute

ISCAR FF EW D1.5-2.5-CF4-09-C Milling Cutter 1.500 Diameter Clickfit 1.574 4.470 OAL 3 Flute

ANSI: FF EW D1.5-2.5-CF4-09-C

ISO: FF EW D1.5-2.5-CF4-09-C

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3103480
Delivery date: 3-5 days
$532.80

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Application Face Milling, Copy Milling, Feed Milling, Ramp Milling, Slot Milling
Package Size 1
Insert Application General Purpose
Made In USA No
Insert/Tool Tool
Shipping State Texas
Dimensional Specifications
Insert Size Ic 9
Cut Dia Min 0.6800 17.27MM
Shank/Pilot Dia 1.5748 40.00MM
Machine Side Connection Type CLICK FIT
Tool Material Steel
Overall Len 4.4700 113.54MM
Depth Of Cut Max 0.8270
Cutter Dia 1.5000 38.10MM - 1-1/2
Cut Dia Max 1.5000 38.10MM - 1-1/2
Machine Side Connection Size 1.5748 40.00MM
Flutes/Inserts 3
Cutting & Machining Properties
Cool Sply Type Through Hole
Insert Shape/Cutter Pocket Shape Trigon
Max Ramp Angle 5.00°
Coolant Thru Yes
Insert Style FF
Fasteners & Connectors
Insert Screw 7000216
