Picture of ISCAR F90SD D2.50-06-1.00-12 Milling Cutter 90.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 6 Flute

ISCAR F90SD D2.50-06-1.00-12 Milling Cutter 90.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 6 Flute

ANSI: F90SD D2.50-06-1.00-12

ISO: F90SD D2.50-06-1.00-12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3319840
Delivery date: 3-5 days
$652.80

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Semi Finishing
Made In USA No
Application Face Milling, Slot Milling, Side Milling
Package Size 1
Insert Type Positive
Shipping State Texas
Insert/Tool Tool
Dimensional Specifications
Cut Dia Max 2.5000 63.50MM - 2-1/2
Tool Material Steel
Insert Size Ic 12
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Min 2.5000 63.50MM - 2-1/2
Machine Side Connection Size 1.0000 25.40MM
Flutes/Inserts 6
Depth Of Cut Max 0.4650
Overall Len 1.7500 44.45MM
Cutter Dia 2.5000 63.50MM - 2-1/2
Cutting & Machining Properties
Cool Sply Type Through Hole
Insert Shape/Cutter Pocket Shape Square
Insert Style SD
Coolant Thru Yes
Fasteners & Connectors
Insert Screw 7006977
