Picture of ISCAR F90SD D2.50-04-1.00-12 Milling Cutter 90.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 4 Flute

ISCAR F90SD D2.50-04-1.00-12 Milling Cutter 90.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 4 Flute

ANSI: F90SD D2.50-04-1.00-12

ISO: F90SD D2.50-04-1.00-12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3319831
Delivery date: 3-5 days
$594.24

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application Semi Finishing, Roughing
Shipping State Texas
Made In USA No
Application Face Milling, Side Milling, Slot Milling
Package Size 1
Insert Type Positive
Dimensional Specifications
Cutter Dia 2.5000 63.50MM - 2-1/2
Cut Dia Min 2.5000 63.50MM - 2-1/2
Machine Side Connection Size 1.0000 25.40MM
Cut Dia Max 2.5000 63.50MM - 2-1/2
Tool Material Steel
Insert Size Ic 12
Machine Side Connection Type Face Mill/Shell Mill
Flutes/Inserts 4
Depth Of Cut Max 0.4650
Overall Len 1.7500 44.45MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Square
Cool Sply Type Through Hole
Insert Style SD
Fasteners & Connectors
Insert Screw 7006977
