Picture of ISCAR F90SD D2.00-03-0.75-12 Milling Cutter 90.0° 2.000 Diameter Face Mill 0.750 1.500 OAL 3 Flute

ISCAR F90SD D2.00-03-0.75-12 Milling Cutter 90.0° 2.000 Diameter Face Mill 0.750 1.500 OAL 3 Flute

ANSI: F90SD D2.00-03-0.75-12

ISO: F90SD D2.00-03-0.75-12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3319830
Delivery date: 3-5 days
$509.76

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Shipping State Texas
Application Side Milling, Slot Milling, Face Milling
Insert Type Positive
Package Size 1
Insert/Tool Tool
Made In USA No
Dimensional Specifications
Cutter Dia 2.0000 50.80MM
Machine Side Connection Size 0.7500 19.05MM
Overall Len 1.5000 38.10MM
Flutes/Inserts 3
Depth Of Cut Max 0.4650
Tool Material Steel
Insert Size Ic 12
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Min 2.0000 50.80MM
Cut Dia Max 2.0000 50.80MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Square
Coolant Thru Yes
Insert Style SD
Cool Sply Type Through Hole
Fasteners & Connectors
Insert Screw 7006977
