  • ISCAR F90LN D6.00-12-2.00-R-N11 Milling Cutter 90.0° 6.000 Diameter Face Mill 2.000 2.000 OAL 12 Flute
Picture of ISCAR F90LN D6.00-12-2.00-R-N11 Milling Cutter 90.0° 6.000 Diameter Face Mill 2.000 2.000 OAL 12 Flute

ISCAR F90LN D6.00-12-2.00-R-N11 Milling Cutter 90.0° 6.000 Diameter Face Mill 2.000 2.000 OAL 12 Flute

ANSI: F90LN D6.00-12-2.00-R-N11

ISO: F90LN D6.00-12-2.00-R-N11

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3103226
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Shipping State Texas
Application Slot Milling, Face Milling, Side Milling
Insert/Tool Tool
Package Size 1
Insert Type Neutral
Made In USA No
Dimensional Specifications
Depth Of Cut Max 0.3940
Tool Material Steel
Overall Len 2.0000 50.80MM
Machine Side Connection Size 2.0000 50.80MM
Flutes/Inserts 12
Insert Size Ic 11
Cut Dia Max 6.0000 152.40MM
Cutter Dia 6.0000 152.40MM
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Min 6.0000 152.40MM
Cutting & Machining Properties
Cool Sply Type External
Insert Style LN
Coolant Thru No
Insert Shape/Cutter Pocket Shape Rectagonal
