  • ISCAR F90LN D3.00-10-1.00-R-N11 Milling Cutter 90.0° 3.000 Diameter Face Mill 1.000 2.000 OAL 10 Flute
Picture of ISCAR F90LN D3.00-10-1.00-R-N11 Milling Cutter 90.0° 3.000 Diameter Face Mill 1.000 2.000 OAL 10 Flute

ISCAR F90LN D3.00-10-1.00-R-N11 Milling Cutter 90.0° 3.000 Diameter Face Mill 1.000 2.000 OAL 10 Flute

ANSI: F90LN D3.00-10-1.00-R-N11

ISO: F90LN D3.00-10-1.00-R-N11

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3103209
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Package Size 1
Insert Application Semi Finishing, Roughing
Shipping State Texas
Application Face Milling, Slot Milling, Side Milling
Insert Type Neutral
Made In USA No
Dimensional Specifications
Tool Material Steel
Cut Dia Max 3.0000 76.20MM
Insert Size Ic 11
Machine Side Connection Size 1.0000 25.40MM
Depth Of Cut Max 0.3940
Flutes/Inserts 10
Cutter Dia 3.0000 76.20MM
Cut Dia Min 3.0000 76.20MM
Machine Side Connection Type Face Mill/Shell Mill
Overall Len 2.0000 50.80MM
Cutting & Machining Properties
Coolant Thru No
Insert Shape/Cutter Pocket Shape Rectagonal
Insert Style LN
Cool Sply Type External
Fasteners & Connectors
Insert Screw 7002495
