  • ISCAR F90LN D3.00-07-1.00-L-N11 Milling Cutter 90.0° 3.000 Diameter Face Mill 1.000 2.000 OAL 7 Flute
Picture of ISCAR F90LN D3.00-07-1.00-L-N11 Milling Cutter 90.0° 3.000 Diameter Face Mill 1.000 2.000 OAL 7 Flute

ISCAR F90LN D3.00-07-1.00-L-N11 Milling Cutter 90.0° 3.000 Diameter Face Mill 1.000 2.000 OAL 7 Flute

ANSI: F90LN D3.00-07-1.00-L-N11

ISO: F90LN D3.00-07-1.00-L-N11

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3103208
Delivery date: 3-5 days
$853.44

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Face Milling, Slot Milling, Side Milling
Insert/Tool Tool
Insert Type Neutral
Made In USA No
Insert Application Roughing, Semi Finishing
Package Size 1
Shipping State Texas
Dimensional Specifications
Depth Of Cut Max 0.3940
Machine Side Connection Size 1.0000 25.40MM
Insert Size Ic 11
Flutes/Inserts 7
Tool Material Steel
Cutter Dia 3.0000 76.20MM
Cut Dia Min 3.0000 76.20MM
Machine Side Connection Type Face Mill/Shell Mill
Overall Len 2.0000 50.80MM
Cut Dia Max 3.0000 76.20MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Rectagonal
Cool Sply Type External
Coolant Thru No
Insert Style LN
Fasteners & Connectors
Insert Screw 7002495
