  • ISCAR F90LN D2.50-06-1.00-R-N11 Milling Cutter 90.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 6 Flute
Picture of ISCAR F90LN D2.50-06-1.00-R-N11 Milling Cutter 90.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 6 Flute

ISCAR F90LN D2.50-06-1.00-R-N11 Milling Cutter 90.0° 2.500 Diameter Face Mill 1.000 1.750 OAL 6 Flute

ANSI: F90LN D2.50-06-1.00-R-N11

ISO: F90LN D2.50-06-1.00-R-N11

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3103204
Delivery date: 3-5 days
$766.08

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Semi Finishing
Made In USA No
Shipping State Texas
Insert Type Neutral
Application Side Milling, Face Milling, Slot Milling
Package Size 1
Insert/Tool Tool
Dimensional Specifications
Cutter Dia 2.5000 63.50MM - 2-1/2
Cut Dia Min 2.5000 63.50MM - 2-1/2
Machine Side Connection Size 1.0000 25.40MM
Cut Dia Max 2.5000 63.50MM - 2-1/2
Machine Side Connection Type Face Mill/Shell Mill
Depth Of Cut Max 0.3940
Flutes/Inserts 6
Overall Len 1.7500 44.45MM
Insert Size Ic 11
Tool Material Steel
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Rectagonal
Insert Style LN
Cool Sply Type External
Coolant Thru No
Fasteners & Connectors
Insert Screw 7002495
