  • ISCAR ERW D020A032-3-M16-12 Milling Cutter Button Cutter 0.787 Diameter Screw On M16 2.559 OAL 3 Flute
Picture of ISCAR ERW D020A032-3-M16-12 Milling Cutter Button Cutter 0.787 Diameter Screw On M16 2.559 OAL 3 Flute

ISCAR ERW D020A032-3-M16-12 Milling Cutter Button Cutter 0.787 Diameter Screw On M16 2.559 OAL 3 Flute

ANSI: ERW D020A032-3-M16-12

ISO: ERW D020A032-3-M16-12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3104906
Delivery date: 3-5 days
$388.80

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Roughing, Semi Finishing
Application Round Milling, Ramp Milling, Face Milling, Pocket Milling
Made In USA No
Shipping State Texas
Package Size 1
Insert/Tool Tool
Insert Type Positive
Dimensional Specifications
Cut Dia Max 1.2600 32.00MM
Flutes/Inserts 3
Insert Size Ic 12
Cutter Dia 0.7870 19.99MM
Overall Len 2.5590 65.00MM
Depth Of Cut Max 0.2360
Tool Material Steel
Machine Side Connection Size M16
Cut Dia Min 0.7870 19.99MM
Machine Side Connection Type Screw On
Cutting & Machining Properties
Coolant Thru Yes
Insert Style RC
Cool Sply Type Through Hole
Insert Shape/Cutter Pocket Shape Round
Max Ramp Angle 7.00°
Fasteners & Connectors
Insert Screw 7004469
