Picture of ISCAR E90X D.38-W .50-06 Milling Cutter 90.0° 0.375 Diameter Weldon 0.500 2.750 OAL 1 Flute

ISCAR E90X D.38-W .50-06 Milling Cutter 90.0° 0.375 Diameter Weldon 0.500 2.750 OAL 1 Flute

ANSI: E90X D.38-W .50-06

ISO: E90X D.38-W .50-06

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3110359
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Side Milling, Slot Milling, Face Milling
Insert Application Roughing, Semi Finishing
Made In USA No
Insert/Tool Tool
Insert Type Positive
Shipping State Texas
Package Size 1
Dimensional Specifications
Depth Of Cut Max 0.2200
Cut Dia Min 0.3750 9.53MM - 3/8
Cut Dia Max 0.3750 9.53MM - 3/8
Insert Size Ic 6
Flutes/Inserts 1
Tool Material Steel
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Machine Side Connection Size 0.5000 12.70MM
Machine Side Connection Type Weldon
Cutter Dia 0.3750 9.53MM - 3/8
Overall Len 2.7500 69.85MM
Cutting & Machining Properties
Max Ramp Angle 1.00°
Insert Shape/Cutter Pocket Shape Square
Insert Style SO
Cool Sply Type External
Coolant Thru No
Fasteners & Connectors
Insert Screw 7000836
