Picture of ISCAR DGTR 25.4B-3XL-D65 Cut Off,Grooving Stick Tool 1.000 Tool

ISCAR DGTR 25.4B-3XL-D65 Cut Off,Grooving Stick Tool 1.000 Tool

ANSI: DGTR 25.4B-3XL-D65

ISO: DGTR 25.4B-3XL-D65

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC2302992
Delivery date: 3-5 days
$201.60

Details

Integral shank reinforced parting and grooving tools for parting up to 2.56" diameters.

For insert depth capacity table, click on "More Info"

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Package Size 1
Shipping State Texas
Insert Application General Purpose
Made In USA No
Insert/Tool Tool
Application Ext.Grooving, Parting
Dimensional Specifications
Tool Width 1.0000
Insert Size Ic 3, 2
Depth Of Cut Max 1.2800
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 5.9100 150.11MM
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Cutting & Machining Properties
Inter/Extern External
Hand R/L Right
Insert Shape/Cutter Pocket Shape Dog Bone
Insert Style DG
