Picture of ISCAR DGTL 19B-2XL-D60 Cut Off,Grooving Stick Tool 0.787 Tool

ISCAR DGTL 19B-2XL-D60 Cut Off,Grooving Stick Tool 0.787 Tool

ANSI: DGTL 19B-2XL-D60

ISO: DGTL 19B-2XL-D60

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC2302851
Delivery date: 3-5 days
$192.00

Details

Integral shank reinforced parting and grooving tools for parting up to 2.56" diameters.

For insert depth capacity table, click on "More Info"

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Ext.Grooving, Parting
Insert Application General Purpose
Made In USA No
Insert Type Positive
Package Size 1
Shipping State Texas
Dimensional Specifications
Tool Width 0.7520
Machine Side Connection Size 0.7874 20.00MM
Shank/Pilot Dia 0.7874 20.00MM
Insert Size Ic 2, 3
Tool Material Steel
Machine Side Connection Type Stick Tool
Overall Len 5.9100 150.11MM
Depth Of Cut Max 1.1800
Cutting & Machining Properties
Hand R/L Left
Insert Style DG
Inter/Extern External
Insert Shape/Cutter Pocket Shape Dog Bone
