  • ISCAR 3M F90AX D12.0-18-2.50-20 Milling Cutter 90.0° 12.00 Diameter Face Mill 2.500 2.480 OAL 18 Flute
Picture of ISCAR 3M F90AX D12.0-18-2.50-20 Milling Cutter 90.0° 12.00 Diameter Face Mill 2.500 2.480 OAL 18 Flute

ISCAR 3M F90AX D12.0-18-2.50-20 Milling Cutter 90.0° 12.00 Diameter Face Mill 2.500 2.480 OAL 18 Flute

ANSI: 3M F90AX D12.0-18-2.50-20

ISO: 3M F90AX D12.0-18-2.50-20

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: ISC3181167
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Type Positive
Application Face Milling, Side Milling, Slot Milling
Shipping State Texas
Insert Application Roughing
Package Size 1
Made In USA No
Dimensional Specifications
Insert Size Ic 20
Depth Of Cut Max 0.7900
Tool Material Steel
Machine Side Connection Size 2.5000 63.50MM
Cutter Dia 12.0000 304.80MM
Overall Len 2.4800 62.99MM
Flutes/Inserts 18
Cut Dia Min 12.0000 304.80MM
Cut Dia Max 12.0000 304.80MM
Machine Side Connection Type Face Mill/Shell Mill
Cutting & Machining Properties
Insert Style AX
Seat/Nest 5601959
Cool Sply Type External
Coolant Thru No
Insert Shape/Cutter Pocket Shape Parallelogram
Fasteners & Connectors
Insert Screw 7002791
Seat Screw 7001998
