Picture of Iscar 16IL 1.25 ISO IC08 Insert Iso Thread Int.Threading Insert Full Profile 1.25mm Metric

Iscar 16IL 1.25 ISO IC08 Insert Iso Thread Int.Threading Insert Full Profile 1.25mm Metric

Part Number: ISC5902590 ISO: 16IL 1.25 ISO IC08 ANSI:16IL 1.25 ISO IC08

Need Assistance or Service? Please call 262-251-4020

Manufacturer: ISCAR
SKU: 1025075
Vendor: Sussex Tool and Supply
$11.19
This product has a minimum quantity of 10
ISCAR 5902590 Triangle Insert Positive Uncoated An uncoated, fine grain carbide grade. Used for stainless steel and high temperature alloys at low to medium cutting speeds.
Products specifications
Attribute name Attribute value
Shipping State TEXAS
Made In USA NO
Cutter Type Insert
Cutting Edge Mat Carbide
Cut Rating Stainless Steel, Ductile Iron, <48HRC Steel, Gray Iron, High Temp
Insert/Tool INSERT
Cut Type General Purpose
Corner Radius 0.0040 0.10MM
Insert Style ISO
Insert Shape/Cutter Pocket Shape Triangle
Grade IC08
Insert Type Positive
Insert Size Ic 16
Insert Fits ISO Thread
Hand Left Hand
Thread Pitch 1.25MM
Thread Type METRIC
Inter/Extern Internal
Full Or Partial Profile Full Profile
Threed Teeth 1
