Picture of INGERSOLL TRGSC01I010-03-00 Milling Cutter 90.0° 1.000 Cylindrical 1.0000 3 Flute 0.4331 Max DOC

INGERSOLL TRGSC01I010-03-00 Milling Cutter 90.0° 1.000 Cylindrical 1.0000 3 Flute 0.4331 Max DOC

ANSI: TRGSC01I010-03-00

ISO: TRGSC01I010-03-00

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING2718079
Delivery date: 3-5 days
$587.07
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Negative
Made In USA No
Shipping State Illinois
Application Face Milling, Side Milling
Insert Application Roughing, Semi Finishing
Package Size 1
Insert/Tool Tool
Dimensional Specifications
Cutter Dia 1.0000 25.40MM
Cut Dia Min 0.9500 24.13MM
Cut Dia Max 1.0000 25.40MM
Machine Side Connection Type Cylindrical
Machine Side Connection Size 1.0000 25.40MM
Shank/Pilot Dia 1.0000 25.40MM
Tool Material Aluminum/Steel
Flutes/Inserts 3
Depth Of Cut Max 0.4331
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Insert Style TR
Coolant Thru No
