Picture of INGERSOLL TN1N-40R01 Milling Cutter 45.0° 4.000 Shell Arbor 1.5000 6 Flute 0.33 Max DOC 2.375 OAL

INGERSOLL TN1N-40R01 Milling Cutter 45.0° 4.000 Shell Arbor 1.5000 6 Flute 0.33 Max DOC 2.375 OAL

ANSI: TN1N-40R01

ISO: TN1N-40R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3025683
Delivery date: 3-5 days
$942.67

Details

FACE MILL 4 CUTTING EDGES, EXTREMELY THICK INSERT GIVES IT GREAT STRENGTH.

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Negative
Shipping State Illinois
Insert Application Roughing, Finishing, Semi Finishing
Made In USA No
Application Face Milling
Package Size 1
Insert/Tool Tool
Dimensional Specifications
Tool Material Steel
Cutter Dia 4.0000 101.60MM
Cut Dia Max 4.7500 120.65MM
Overall Len 2.3750 60.33MM
Machine Side Connection Type Face Mill/Shell Mill
Machine Side Connection Size 1.5000 38.10MM
Cut Dia Min 4.0000 101.60MM
Insert Size Ic 16
Flutes/Inserts 6
Depth Of Cut Max 0.3300
Cutting & Machining Properties
Coolant Thru No
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AN
