Picture of INGERSOLL TN1N-30R01 Milling Cutter 45.0° 3.000 Shell Arbor 1.0000 5 Flute 0.33 Max DOC 1.750 OAL

INGERSOLL TN1N-30R01 Milling Cutter 45.0° 3.000 Shell Arbor 1.0000 5 Flute 0.33 Max DOC 1.750 OAL

ANSI: TN1N-30R01

ISO: TN1N-30R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3025681
Delivery date: 3-5 days
$793.33

Details

FACE MILL 4 CUTTING EDGES, EXTREMELY THICK INSERT GIVES IT GREAT STRENGTH.

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Negative
Insert Application Roughing, Semi Finishing, Finishing
Made In USA No
Shipping State Illinois
Package Size 1
Insert/Tool Tool
Application Face Milling
Dimensional Specifications
Cutter Dia 3.0000 76.20MM
Overall Len 1.7500 44.45MM
Insert Size Ic 16
Machine Side Connection Size 1.0000 25.40MM
Cut Dia Min 3.0000 76.20MM
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Max 3.7500 95.25MM
Depth Of Cut Max 0.3300
Tool Material Steel
Flutes/Inserts 5
Cutting & Machining Properties
Coolant Thru No
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AN
