  • INGERSOLL TJ6Q-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 7 Flute Coolant 0.43 Max DOC 1.750 OAL
Picture of INGERSOLL TJ6Q-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 7 Flute Coolant 0.43 Max DOC 1.750 OAL

INGERSOLL TJ6Q-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 7 Flute Coolant 0.43 Max DOC 1.750 OAL

ANSI: TJ6Q-30R01

ISO: TJ6Q-30R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031353
Delivery date: 3-5 days
$854.00

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Type Negative
Made In USA No
Shipping State Illinois
Application Face Milling, Side Milling
Insert Application Roughing, Semi Finishing
Package Size 1
Dimensional Specifications
Machine Side Connection Size 1.0000 25.40MM
Cutter Dia 3.0000 76.20MM
Tool Material Steel
Depth Of Cut Max 0.4300
Cut Dia Min 3.0000 76.20MM
Machine Side Connection Type Face Mill/Shell Mill
Flutes/Inserts 7
Insert Size Ic 12
Overall Len 1.7500 44.45MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Coolant Thru Yes
Insert Style AN
Max Ramp Angle 0.30°
