  • INGERSOLL TJ6Q-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 0.7500 6 Flute Coolant 0.43 Max DOC 1.570 OAL
Picture of INGERSOLL TJ6Q-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 0.7500 6 Flute Coolant 0.43 Max DOC 1.570 OAL

INGERSOLL TJ6Q-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 0.7500 6 Flute Coolant 0.43 Max DOC 1.570 OAL

ANSI: TJ6Q-25R01

ISO: TJ6Q-25R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031351
Delivery date: 3-5 days
$674.80

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Type Negative
Insert Application Roughing, Semi Finishing
Made In USA No
Application Side Milling, Face Milling
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Insert Size Ic 12
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Min 2.5000 63.50MM - 2-1/2
Cutter Dia 2.5000 63.50MM - 2-1/2
Machine Side Connection Size 0.7500 19.05MM
Flutes/Inserts 6
Depth Of Cut Max 0.4300
Tool Material Steel
Overall Len 1.5700 39.88MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AN
Max Ramp Angle 0.40°
