  • INGERSOLL TJ6N-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 3 Flute Coolant 0.59 Max DOC 1.570 OAL
Picture of INGERSOLL TJ6N-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 3 Flute Coolant 0.59 Max DOC 1.570 OAL

INGERSOLL TJ6N-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 3 Flute Coolant 0.59 Max DOC 1.570 OAL

ANSI: TJ6N-20R01

ISO: TJ6N-20R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3025667
Delivery date: 3-5 days
$490.93

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Application Side Milling, Face Milling
Package Size 1
Insert/Tool Tool
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Depth Of Cut Max 0.5900
Insert Size Ic 16
Cutter Dia 2.0000 50.80MM
Cut Dia Min 2.0000 50.80MM
Flutes/Inserts 3
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Overall Len 1.5700 39.88MM
Machine Side Connection Type Face Mill/Shell Mill
Cutting & Machining Properties
Insert Style AN
Insert Shape/Cutter Pocket Shape Parallelogram
Max Ramp Angle 1.00°
Coolant Thru Yes
