  • INGERSOLL TJ5N-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 1.0000 5 Flute Coolant 0.59 Max DOC 1.750 OAL
Picture of INGERSOLL TJ5N-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 1.0000 5 Flute Coolant 0.59 Max DOC 1.750 OAL

INGERSOLL TJ5N-25R01 Milling Cutter 90.0° 2.500 Shell Arbor 1.0000 5 Flute Coolant 0.59 Max DOC 1.750 OAL

ANSI: TJ5N-25R01

ISO: TJ5N-25R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3025670
Delivery date: 3-5 days
$614.13

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Application Face Milling, Side Milling
Package Size 1
Insert Type Negative
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Insert Size Ic 16
Machine Side Connection Size 1.0000 25.40MM
Machine Side Connection Type Face Mill/Shell Mill
Tool Material Steel
Cut Dia Min 2.5000 63.50MM - 2-1/2
Cutter Dia 2.5000 63.50MM - 2-1/2
Flutes/Inserts 5
Depth Of Cut Max 0.5900
Overall Len 1.7500 44.45MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AN
Max Ramp Angle 0.60°
Coolant Thru Yes
