  • INGERSOLL TJ5N-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 4 Flute Coolant 0.59 Max DOC 1.570 OAL
Picture of INGERSOLL TJ5N-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 4 Flute Coolant 0.59 Max DOC 1.570 OAL

INGERSOLL TJ5N-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 4 Flute Coolant 0.59 Max DOC 1.570 OAL

ANSI: TJ5N-20R01

ISO: TJ5N-20R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3025668
Delivery date: 3-5 days
$499.33

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Package Size 1
Insert Type Negative
Made In USA No
Shipping State Illinois
Application Side Milling, Face Milling
Insert/Tool Tool
Dimensional Specifications
Cut Dia Min 2.0000 50.80MM
Depth Of Cut Max 0.5900
Flutes/Inserts 4
Machine Side Connection Type Face Mill/Shell Mill
Insert Size Ic 16
Cutter Dia 2.0000 50.80MM
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Overall Len 1.5700 39.88MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AN
Max Ramp Angle 1.00°
