INGERSOLL TD0800012S4R01 0.3150 (8.000 mm)-0.3504 (8.900 mm) GoldTwist Body

ISO: TD0800012S4R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3212745
Delivery date: 3-5 days
$185.73

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Single Insert Drilling, Drilling
Shipping State Illinois
Made In USA No
Package Size 1
Dimensional Specifications
Machine Side Connection Type Boring Bar,Weldon
Flute Length 0.4700 11.94MM
Cut Dia Min 0.3150 8.00MM
Shank/Pilot Dia 0.5000 12.70MM - 1/2
Cutter Dia 0.3150 8.00MM
Cut Dia Max 0.3310 8.41MM
Flutes/Inserts 2
Dia Deep 1.5XD
Included Angle 140°
Machine Side Connection Size 0.5000 12.70MM
Tool Material Carbide
Cutting & Machining Properties
Cutting Edge Mat Carbide
Coolant Thru Yes
