  • INGERSOLL SJ6Y-02R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 5 Flute Coolant 0.31 Max DOC 1.570 OAL
Picture of INGERSOLL SJ6Y-02R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 5 Flute Coolant 0.31 Max DOC 1.570 OAL

INGERSOLL SJ6Y-02R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 5 Flute Coolant 0.31 Max DOC 1.570 OAL

ANSI: SJ6Y-02R01

ISO: SJ6Y-02R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3029702
Delivery date: 3-5 days
$573.07

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Face Milling, Side Milling
Insert Application Semi Finishing, Roughing
Insert/Tool Tool
Insert Type Negative
Made In USA No
Shipping State Illinois
Package Size 1
Dimensional Specifications
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Overall Len 1.5700 39.88MM
Flutes/Inserts 5
Machine Side Connection Type Face Mill/Shell Mill
Insert Size Ic 21
Cutter Dia 2.0000 50.80MM
Depth Of Cut Max 0.3100
Cut Dia Min 2.0000 50.80MM
Cutting & Machining Properties
Insert Style DG
Insert Shape/Cutter Pocket Shape Rectagonal
Coolant Thru Yes
