  • INGERSOLL SJ5Y-02R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 7 Flute Coolant 0.31 Max DOC 1.570 OAL
Picture of INGERSOLL SJ5Y-02R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 7 Flute Coolant 0.31 Max DOC 1.570 OAL

INGERSOLL SJ5Y-02R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 7 Flute Coolant 0.31 Max DOC 1.570 OAL

ANSI: SJ5Y-02R01

ISO: SJ5Y-02R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3029703
Delivery date: 3-5 days
$607.60

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Application Side Milling, Face Milling
Package Size 1
Insert/Tool Tool
Shipping State Illinois
Insert Type Negative
Made In USA No
Dimensional Specifications
Cutter Dia 2.0000 50.80MM
Machine Side Connection Size 0.7500 19.05MM
Depth Of Cut Max 0.3100
Flutes/Inserts 7
Tool Material Steel
Overall Len 1.5700 39.88MM
Machine Side Connection Type Face Mill/Shell Mill
Insert Size Ic 21
Cut Dia Min 2.0000 50.80MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Style DG
Insert Shape/Cutter Pocket Shape Rectagonal
