INGERSOLL SEKT 12T3AFTN-M IN2510 Milling Insert Square 0.043 TiAIN + TiN ISO Milling Insert

ANSI: SEKT 12T3AFTN-M IN2510

ISO: SEKT12T3AFTN-M IN2510

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING5874159
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Grade and Coating Description

HARD GRADE FOR STEEL,STAINLESS,IRON AND HIGH TEMP

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Insert Application Roughing, Semi Finishing
Made In USA No
Shipping State Illinois
Coating TiAIN + TiN
Package Size 10
Grade IN2510
Insert/Tool Insert
Application Milling Insert
Dimensional Specifications
Corner Radius 0.0430 1.09MM
Cut Rating >50HRC Steel, Ductile Iron, Gray Iron, Graphite
Depth Of Cut Max 0.2700
Insert Size Ic 12
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Square
Cutting Edge Mat Carbide
Insert Style SE
