Picture of INGERSOLL ON5H-60R01 Milling Cutter 45.0° 6.000 Shell Arbor 1.5000 18 Flute 0.12 Max DOC 2.375 OAL

INGERSOLL ON5H-60R01 Milling Cutter 45.0° 6.000 Shell Arbor 1.5000 18 Flute 0.12 Max DOC 2.375 OAL

ANSI: ON5H-60R01

ISO: ON5H-60R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3030045
Delivery date: 3-5 days
$1,904.00

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing, Finishing
Insert Type Negative
Shipping State Illinois
Made In USA No
Insert/Tool Tool
Application Face Milling
Package Size 1
Dimensional Specifications
Cut Dia Max 6.3300 160.78MM
Insert Size Ic 5
Machine Side Connection Type Face Mill/Shell Mill
Tool Material Steel
Cutter Dia 6.0000 152.40MM
Depth Of Cut Max 0.1200
Cut Dia Min 6.0000 152.40MM
Overall Len 2.3750 60.33MM
Flutes/Inserts 18
Machine Side Connection Size 1.5000 38.10MM
Cutting & Machining Properties
Insert Style ON
Insert Shape/Cutter Pocket Shape Octagonal
Coolant Thru No
