  • INGERSOLL KJ6P-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 4 Flute Coolant 0.57 Max DOC 1.750 OAL
Picture of INGERSOLL KJ6P-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 4 Flute Coolant 0.57 Max DOC 1.750 OAL

INGERSOLL KJ6P-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 4 Flute Coolant 0.57 Max DOC 1.750 OAL

ANSI: KJ6P-20R01

ISO: KJ6P-20R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING2926828
Delivery date: 3-5 days
$597.33

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application Roughing, Semi Finishing
Application Side Milling, Face Milling, Pocket Milling, Ramp Milling, Slot Milling
Insert Type Positive
Package Size 1
Made In USA No
Shipping State Illinois
Dimensional Specifications
Machine Side Connection Size 0.7500 19.05MM
Flutes/Inserts 4
Overall Len 1.7500 44.45MM
Depth Of Cut Max 0.5700
Cutter Dia 2.0000 50.80MM
Insert Size Ic 13
Machine Side Connection Type Face Mill/Shell Mill
Tool Material Steel
Cut Dia Min 2.0000 50.80MM
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Triangle
Insert Style TH
Max Ramp Angle 1.50°
