  • INGERSOLL KJ6G080R00 Milling Cutter 90.0° 3.150 Shell Arbor 0.6300 6 Flute Coolant 0.4331 Max DOC 1.968 OAL
Picture of INGERSOLL KJ6G080R00 Milling Cutter 90.0° 3.150 Shell Arbor 0.6300 6 Flute Coolant 0.4331 Max DOC 1.968 OAL

INGERSOLL KJ6G080R00 Milling Cutter 90.0° 3.150 Shell Arbor 0.6300 6 Flute Coolant 0.4331 Max DOC 1.968 OAL

ANSI: KJ6G080R00

ISO: KJ6G080R00

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3057623
Delivery date: 3-5 days
$840.00
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Application Face Milling, Ramp Milling, Side Milling, Slot Milling, Pocket Milling
Package Size 1
Made In USA No
Insert Type Positive
Insert/Tool Tool
Shipping State Illinois
Dimensional Specifications
Insert Size Ic 10
Overall Len 1.9685 50.00MM
Flutes/Inserts 6
Cutter Dia 3.1500 80.01MM
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Min 3.1500 80.01MM
Machine Side Connection Size 0.6299 16.00MM
Depth Of Cut Max 0.4331
Tool Material Steel
Cutting & Machining Properties
Coolant Thru Yes
Max Ramp Angle 0.80°
Insert Style TH
Insert Shape/Cutter Pocket Shape Triangle
