Picture of INGERSOLL KJ6G063R00 Milling Cutter 90.0° 2.480 Shell Arbor 0.8661 4 Flute Coolant 0.4331 Max DOC 1.574 OAL

INGERSOLL KJ6G063R00 Milling Cutter 90.0° 2.480 Shell Arbor 0.8661 4 Flute Coolant 0.4331 Max DOC 1.574 OAL

ANSI: KJ6G063R00

ISO: KJ6G063R00

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3057622
Delivery date: 3-5 days
$672.93
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Insert Type Positive
Application Face Milling, Slot Milling, Pocket Milling, Ramp Milling, Side Milling
Insert/Tool Tool
Package Size 1
Made In USA No
Shipping State Illinois
Dimensional Specifications
Cut Dia Min 2.4800 62.99MM
Insert Size Ic 10
Depth Of Cut Max 0.4331
Tool Material Steel
Cutter Dia 2.4800 62.99MM
Flutes/Inserts 4
Machine Side Connection Type Face Mill/Shell Mill
Machine Side Connection Size 0.8661 22.00MM
Overall Len 1.5748 40.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Coolant Thru Yes
Max Ramp Angle 1.10°
Insert Style TH
