Picture of INGERSOLL KJ6G-50R01 Milling Cutter 90.0° 5.000 Shell Arbor 1.5000 11 Flute 0.41 Max DOC 2.000 OAL

INGERSOLL KJ6G-50R01 Milling Cutter 90.0° 5.000 Shell Arbor 1.5000 11 Flute 0.41 Max DOC 2.000 OAL

ANSI: KJ6G-50R01

ISO: KJ6G-50R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031437
Delivery date: 3-5 days
$1,297.33

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ramp Milling, Slot Milling, Pocket Milling, Face Milling, Side Milling
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Insert Type Positive
Package Size 1
Insert Application Semi Finishing, Roughing
Dimensional Specifications
Depth Of Cut Max 0.4100
Flutes/Inserts 11
Machine Side Connection Type Face Mill/Shell Mill
Overall Len 2.0000 50.80MM
Insert Size Ic 10
Tool Material Steel
Cutter Dia 5.0000 127.00MM
Machine Side Connection Size 1.5000 38.10MM
Cut Dia Min 5.0000 127.00MM
Cutting & Machining Properties
Insert Style TH
Insert Shape/Cutter Pocket Shape Triangle
Coolant Thru No
Max Ramp Angle 0.50°
