  • INGERSOLL KJ6D040R00 Milling Cutter 90.0° 1.575 Shell Arbor 0.6300 4 Flute Coolant 0.2756 Max DOC 1.574 OAL
Picture of INGERSOLL KJ6D040R00 Milling Cutter 90.0° 1.575 Shell Arbor 0.6300 4 Flute Coolant 0.2756 Max DOC 1.574 OAL

INGERSOLL KJ6D040R00 Milling Cutter 90.0° 1.575 Shell Arbor 0.6300 4 Flute Coolant 0.2756 Max DOC 1.574 OAL

ANSI: KJ6D040R00

ISO: KJ6D040R00

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3057616
Delivery date: 3-5 days
$512.40
Products specifications
Attribute name Attribute value
General Product Information
Application Ramp Milling, Side Milling, Pocket Milling, Face Milling, Slot Milling
Package Size 1
Insert Application Semi Finishing, Roughing
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Insert Type Positive
Dimensional Specifications
Insert Size Ic 6
Flutes/Inserts 4
Depth Of Cut Max 0.2756
Cut Dia Min 1.5750 40.01MM
Machine Side Connection Type Face Mill/Shell Mill
Cutter Dia 1.5750 40.01MM
Tool Material Steel
Overall Len 1.5748 40.00MM
Machine Side Connection Size 0.6299 16.00MM
Cutting & Machining Properties
Insert Style TH
Coolant Thru Yes
Max Ramp Angle 1.30°
Insert Shape/Cutter Pocket Shape Triangle
