  • INGERSOLL KJ6D-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 9 Flute Coolant 0.275 Max DOC 1.750 OAL
Picture of INGERSOLL KJ6D-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 9 Flute Coolant 0.275 Max DOC 1.750 OAL

INGERSOLL KJ6D-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 9 Flute Coolant 0.275 Max DOC 1.750 OAL

ANSI: KJ6D-30R01

ISO: KJ6D-30R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031430
Delivery date: 3-5 days
$854.00

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Pocket Milling, Face Milling, Slot Milling, Ramp Milling, Side Milling
Insert Type Positive
Insert Application Roughing, Semi Finishing
Made In USA No
Shipping State Illinois
Package Size 1
Dimensional Specifications
Machine Side Connection Size 1.0000 25.40MM
Flutes/Inserts 9
Tool Material Steel
Cutter Dia 3.0000 76.20MM
Overall Len 1.7500 44.45MM
Cut Dia Min 3.0000 76.20MM
Machine Side Connection Type Face Mill/Shell Mill
Insert Size Ic 10
Depth Of Cut Max 0.2750
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Insert Style TH
Coolant Thru Yes
Max Ramp Angle 0.40°
