  • INGERSOLL KJ5P080R00 Milling Cutter 90.0° 3.150 Shell Arbor 0.6300 7 Flute Coolant 0.5906 Max DOC 1.968 OAL
Picture of INGERSOLL KJ5P080R00 Milling Cutter 90.0° 3.150 Shell Arbor 0.6300 7 Flute Coolant 0.5906 Max DOC 1.968 OAL

INGERSOLL KJ5P080R00 Milling Cutter 90.0° 3.150 Shell Arbor 0.6300 7 Flute Coolant 0.5906 Max DOC 1.968 OAL

ANSI: KJ5P080R00

ISO: KJ5P080R00

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031261
Delivery date: 3-5 days
$829.73
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Insert Type Positive
Application Face Milling, Slot Milling, Pocket Milling, Ramp Milling, Side Milling
Insert/Tool Tool
Shipping State Illinois
Package Size 1
Made In USA No
Dimensional Specifications
Overall Len 1.9685 50.00MM
Machine Side Connection Size 0.6299 16.00MM
Cut Dia Min 3.1500 80.01MM
Tool Material Steel
Insert Size Ic 13
Depth Of Cut Max 0.5906
Flutes/Inserts 7
Cutter Dia 3.1500 80.01MM
Machine Side Connection Type Face Mill/Shell Mill
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Coolant Thru Yes
Max Ramp Angle 1.30°
Insert Style TH
