  • INGERSOLL KJ5G-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 5 Flute Coolant 0.41 Max DOC 1.570 OAL
Picture of INGERSOLL KJ5G-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 5 Flute Coolant 0.41 Max DOC 1.570 OAL

INGERSOLL KJ5G-20R01 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 5 Flute Coolant 0.41 Max DOC 1.570 OAL

ANSI: KJ5G-20R01

ISO: KJ5G-20R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031431
Delivery date: 3-5 days
$587.07

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Application Pocket Milling, Face Milling, Slot Milling, Ramp Milling, Side Milling
Shipping State Illinois
Package Size 1
Insert Application Semi Finishing, Roughing
Insert Type Positive
Made In USA No
Dimensional Specifications
Tool Material Steel
Overall Len 1.5700 39.88MM
Insert Size Ic 10
Machine Side Connection Size 0.7500 19.05MM
Flutes/Inserts 5
Cut Dia Min 2.0000 50.80MM
Cutter Dia 2.0000 50.80MM
Depth Of Cut Max 0.4100
Machine Side Connection Type Face Mill/Shell Mill
Cutting & Machining Properties
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Triangle
Max Ramp Angle 1.50°
Insert Style TH
