Picture of INGERSOLL Hole Making Mill Boring Boring Head Boring Bar Boring Bar 0.629 Steel

INGERSOLL Hole Making Mill Boring Boring Head Boring Bar Boring Bar 0.629 Steel

ISO: B3.22

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3240059
Delivery date: 3-5 days
$175.27

Features And Benefits

Boring Bar (steel) Dia. Range: .236" - 1.18" Dia. Range: 6-30 mm D’Andrea MHD compatible

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Application Mill Boring
Insert/Tool Tool
Insert Type Positive
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Dimensional Specifications
Cut Dia Min 0.8660 22.00MM
Shank/Pilot Dia 0.6299 16.00MM
Cut Dia Max 1.1810 30.00MM
Tool Material Steel
Tool Over Hang 2.6770
Machine Side Connection Size 0.6299 16.00MM
Insert Size Ic 09 "73"
Machine Side Connection Type Boring Bar
Cutting & Machining Properties
Inter/Extern Internal
Insert Style TP
Insert Shape/Cutter Pocket Shape Triangle
