Picture of INGERSOLL Hole Making Mill Boring Boring Head Boring Bar Boring Bar 0.629 Steel

INGERSOLL Hole Making Mill Boring Boring Head Boring Bar Boring Bar 0.629 Steel

ISO: B3.14

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3240056
Delivery date: 3-5 days
$154.73

Features And Benefits

Boring Bar (steel) Dia. Range: .236" - 1.18" Dia. Range: 6-30 mm D’Andrea MHD compatible

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Package Size 1
Insert Application General Purpose
Made In USA No
Insert/Tool Tool
Shipping State Illinois
Application Mill Boring
Dimensional Specifications
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Cut Dia Max 0.6300 16.00MM
Neck Length 1.9680 49.99MM
Machine Side Connection Type Boring Bar
Tool Material Steel
Insert Size Ic 09 "73"
Tool Over Hang 2.0470
Cut Dia Min 0.5510 14.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Insert Style TP
