Picture of INGERSOLL Hole Making Mill Boring Boring Head Boring Bar Boring Bar 0.629 Steel

INGERSOLL Hole Making Mill Boring Boring Head Boring Bar Boring Bar 0.629 Steel

ISO: B3.10

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3240053
Delivery date: 3-5 days
$145.20

Features And Benefits

Boring Bar (steel) Dia. Range: .236" - 1.18" Dia. Range: 6-30 mm D’Andrea MHD compatible

Products specifications
Attribute name Attribute value
General Product Information
Application Mill Boring
Package Size 1
Insert/Tool Tool
Made In USA No
Insert Application General Purpose
Shipping State Illinois
Insert Type Positive
Dimensional Specifications
Tool Over Hang 1.6920
Cut Dia Min 0.3940 10.01MM
Cut Dia Max 0.4720 11.99MM
Insert Size Ic 09 "73"
Neck Length 1.3770 34.98MM
Tool Material Steel
Machine Side Connection Type Boring Bar
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Insert Style TP
