Picture of INGERSOLL Hole Making Mill Boring Boring Head Boring Bar Boring Bar 0.629 Heavy Metal

INGERSOLL Hole Making Mill Boring Boring Head Boring Bar Boring Bar 0.629 Heavy Metal

ISO: B5.16

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3240065
Delivery date: 3-5 days
$365.93

Features And Benefits

Boring Bar (heavy metal) Ø.236-.708" Ø6-18 mm D’Andrea MHD compatible

Products specifications
Attribute name Attribute value
General Product Information
Insert/Tool Tool
Insert Application General Purpose
Shipping State Illinois
Made In USA No
Package Size 1
Application Mill Boring
Insert Type Positive
Dimensional Specifications
Cut Dia Min 0.6300 16.00MM
Machine Side Connection Type Boring Bar
Neck Length 3.7790 95.99MM
Tool Material Heavy Metal
Machine Side Connection Size 0.6299 16.00MM
Shank/Pilot Dia 0.6299 16.00MM
Insert Size Ic 09 "73"
Cut Dia Max 0.7080 17.98MM
Cutting & Machining Properties
Insert Style TP
Insert Shape/Cutter Pocket Shape Triangle
