Picture of INGERSOLL Hole Making Mill Boring Boring Head Boring Bar Boring Bar 0.629 Heavy Metal

INGERSOLL Hole Making Mill Boring Boring Head Boring Bar Boring Bar 0.629 Heavy Metal

ISO: B5.12

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3240063
Delivery date: 3-5 days
$305.07

Features And Benefits

Boring Bar (heavy metal) Ø.236-.708" Ø6-18 mm D’Andrea MHD compatible

Products specifications
Attribute name Attribute value
General Product Information
Insert Type Positive
Insert/Tool Tool
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Application Mill Boring
Package Size 1
Dimensional Specifications
Cut Dia Min 0.4720 11.99MM
Neck Length 2.8340 71.98MM
Machine Side Connection Size 0.6299 16.00MM
Machine Side Connection Type Boring Bar
Insert Size Ic 09 "73"
Cut Dia Max 0.5510 14.00MM
Shank/Pilot Dia 0.6299 16.00MM
Tool Material Heavy Metal
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Triangle
Insert Style TP
