Picture of INGERSOLL Hole Making Mill Boring Boring Head 45.0°, Chamfer ing Ring O.D. 2.834 Steel

INGERSOLL Hole Making Mill Boring Boring Head 45.0°, Chamfer ing Ring O.D. 2.834 Steel

ISO: AS40.45

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3240160
Delivery date: 3-5 days
Call (262) 251-4020 for pricing

Features And Benefits

Chamfering Tools D’Andrea MHD compatible

Products specifications
Attribute name Attribute value
General Product Information
Package Size 1
Insert/Tool Tool
Insert Type Positive
Application Mill Boring
Insert Application General Purpose
Made In USA No
Shipping State Illinois
Dimensional Specifications
Machine Side Connection Type Ring O.D.
Cut Dia Max 2.8350 72.01MM
Tool Material Steel
Insert Size Ic 11 "32"
Cut Dia Min 1.8110 46.00MM
Shank/Pilot Dia 2.8346 72.00MM
Machine Side Connection Size 2.8346 72.00MM
Overall Len 1.1811 30.00MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape 55.0°
Insert Style DC
