Picture of INGERSOLL EF6J-08R01 Milling Cutter 8.000 Shell Arbor 2.5000 9 Flute Coolant 0.04 Max DOC 2.500 OAL

INGERSOLL EF6J-08R01 Milling Cutter 8.000 Shell Arbor 2.5000 9 Flute Coolant 0.04 Max DOC 2.500 OAL

ANSI: EF6J-08R01

ISO: EF6J-08R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3032616
Delivery date: 3-5 days
$1,689.33

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Finishing
Application Face Milling, Micro Finishing
Insert/Tool Tool
Shipping State Illinois
Insert Type Negative
Made In USA No
Package Size 1
Dimensional Specifications
Overall Len 2.5000 63.50MM
Cutter Dia 8.0000 203.20MM
Cut Dia Max 8.0000 203.20MM
Depth Of Cut Max 0.0400
Tool Material Steel
Machine Side Connection Size 2.5000 63.50MM
Cut Dia Min 7.2350 183.77MM
Machine Side Connection Type Face Mill/Shell Mill
Flutes/Inserts 9
Insert Size Ic 32
Cutting & Machining Properties
Insert Style DG
Insert Shape/Cutter Pocket Shape Rectagonal
Coolant Thru Yes
