Picture of INGERSOLL DM6G160R00 Milling Cutter 70.0° 6.299 Shell Arbor 1.5748 12 Flute 0.23 Max DOC 2.480 OAL

INGERSOLL DM6G160R00 Milling Cutter 70.0° 6.299 Shell Arbor 1.5748 12 Flute 0.23 Max DOC 2.480 OAL

ANSI: DM6G160R00

ISO: DM6G160R00

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3019835
Delivery date: 3-5 days
$1,549.33
Products specifications
Attribute name Attribute value
General Product Information
Application Face Milling
Insert Type Negative
Insert Application Roughing, Semi Finishing
Made In USA No
Insert/Tool Tool
Shipping State Illinois
Package Size 1
Dimensional Specifications
Insert Size Ic 8
Machine Side Connection Type Face Mill/Shell Mill
Cut Dia Max 6.5160 165.51MM
Cutter Dia 6.2990 159.99MM
Machine Side Connection Size 1.5748 40.00MM
Overall Len 2.4803 63.00MM
Tool Material Steel
Depth Of Cut Max 0.2300
Cut Dia Min 6.2990 159.99MM
Flutes/Inserts 12
Cutting & Machining Properties
Insert Style PN
Insert Shape/Cutter Pocket Shape Pentagonal
Coolant Thru No
