  • INGERSOLL DJ5P-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 7 Flute Coolant 0.362 Max DOC 1.750 OAL
Picture of INGERSOLL DJ5P-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 7 Flute Coolant 0.362 Max DOC 1.750 OAL

INGERSOLL DJ5P-30R01 Milling Cutter 90.0° 3.000 Shell Arbor 1.0000 7 Flute Coolant 0.362 Max DOC 1.750 OAL

ANSI: DJ5P-30R01

ISO: DJ5P-30R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3031739
Delivery date: 3-5 days
$760.67

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Semi Finishing, Roughing
Application Side Milling, Face Milling
Package Size 1
Insert/Tool Tool
Insert Type Negative
Made In USA No
Shipping State Illinois
Dimensional Specifications
Overall Len 1.7500 44.45MM
Cut Dia Max 3.0000 76.20MM
Cutter Dia 3.0000 76.20MM
Insert Size Ic 13
Flutes/Inserts 7
Depth Of Cut Max 0.3620
Tool Material Steel
Cut Dia Min 3.0000 76.20MM
Machine Side Connection Type Face Mill/Shell Mill
Machine Side Connection Size 1.0000 25.40MM
Cutting & Machining Properties
Insert Style WN
Coolant Thru Yes
Insert Shape/Cutter Pocket Shape Trigon
