INGERSOLL BOMT130431R IN2505 Milling Insert Paralelagram 0.125 TiAIN + TiN Hipos

ANSI: BOMT130431R IN2505

ISO: BOMT130431R IN2505

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING5872526
Delivery date: 3-5 days
$17.01

Cutting Edge Definition

Cemented carbides are a class of hard materials used extensively for cutting tools, as well as in other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal. Cemented carbides commonly use tungsten carbide (WC), titanium carbide (TiC), or tantalum carbide (TaC) as the aggregate. Mentions of "carbide" or "tungsten carbide" in industrial contexts usually refer to these cemented composites. The cobalt content could vary from 5% to 23% base on application. 8% to 12% are the most common for cutting tools. Ruthenium is used to replace cobalt as a perfered binder for the best cutting performance.

Grade and Coating Description

HARD GRADE FOR STEEL,STAINLESS,IRON AND HIGH TEMP

Products specifications
Attribute name Attribute value
General Product Information
Shipping State Illinois
Insert Application Roughing, Semi Finishing
Made In USA No
Coating TiAIN + TiN
Package Size 10
Insert Type Positive
Insert/Tool Insert
Application Milling Insert
Grade IN2505
Dimensional Specifications
Cut Rating <48HRC Steel, Aluminum, Brass, Copper, Ductile Iron, Gray Iron, High Temp, Stainless Steel
Corner Radius 0.1250 3.18MM
Insert Size Ic 13
Depth Of Cut Max 0.5460
Cutting & Machining Properties
Insert Style BO
Insert Shape/Cutter Pocket Shape Parallelogram
Cutting Edge Mat Carbide
