  • INGERSOLL 5W7K-30R01 Milling Cutter Button Cutter 3.000 Shell Arbor 1.0000 6 Flute 0.315 Max DOC 2.000 OAL
Picture of INGERSOLL 5W7K-30R01 Milling Cutter Button Cutter 3.000 Shell Arbor 1.0000 6 Flute 0.315 Max DOC 2.000 OAL

INGERSOLL 5W7K-30R01 Milling Cutter Button Cutter 3.000 Shell Arbor 1.0000 6 Flute 0.315 Max DOC 2.000 OAL

ANSI: 5W7K-30R01

ISO: 5W7K-30R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3017075
Delivery date: 3-5 days
$739.20

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Application Ramp Milling, Pocket Milling, Face Milling, Round Milling
Insert Application Roughing, Semi Finishing
Made In USA No
Insert/Tool Tool
Shipping State Illinois
Insert Type Positive
Package Size 1
Dimensional Specifications
Insert Size Ic 16
Machine Side Connection Size 1.0000 25.40MM
Cutter Dia 3.0000 76.20MM
Machine Side Connection Type Face Mill/Shell Mill
Overall Len 2.0000 50.80MM
Tool Material Steel
Flutes/Inserts 6
Depth Of Cut Max 0.3150
Cut Dia Max 3.0000 76.20MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Round
Max Ramp Angle 5.50°
Insert Style RH
Coolant Thru No
