Picture of INGERSOLL 5N6F-25R01 Milling Cutter 45.0° 2.500 Shell Arbor 0.7500 6 Flute 0.18 Max DOC 1.570 OAL

INGERSOLL 5N6F-25R01 Milling Cutter 45.0° 2.500 Shell Arbor 0.7500 6 Flute 0.18 Max DOC 1.570 OAL

ANSI: 5N6F-25R01

ISO: 5N6F-25R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3012764
Delivery date: 3-5 days
$468.53

Details

FACE MILL WITH VERY POSITIVE CUTTING ACTION. GREAT FOR LIGH DUTY EQUIPMENT OR LONG REACH APPLICATIONS.

Products specifications
Attribute name Attribute value
General Product Information
Made In USA No
Shipping State Illinois
Insert Type Positive
Application Face Milling
Insert/Tool Tool
Insert Application Medium
Package Size 1
Dimensional Specifications
Machine Side Connection Type Face Mill/Shell Mill
Insert Size Ic 9
Tool Material Steel
Machine Side Connection Size 0.7500 19.05MM
Overall Len 1.5700 39.88MM
Depth Of Cut Max 0.1800
Cutter Dia 2.5000 63.50MM - 2-1/2
Cut Dia Max 2.9000 73.66MM
Cut Dia Min 2.5000 63.50MM - 2-1/2
Flutes/Inserts 6
Cutting & Machining Properties
Insert Style SE
Insert Shape/Cutter Pocket Shape Square
Coolant Thru No
