Picture of INGERSOLL 5H6G-20R02 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 3 Flute 0.41 Max DOC 1.570 OAL

INGERSOLL 5H6G-20R02 Milling Cutter 90.0° 2.000 Shell Arbor 0.7500 3 Flute 0.41 Max DOC 1.570 OAL

ANSI: 5H6G-20R02

ISO: 5H6G-20R02

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3022779
Delivery date: 3-5 days
$559.07

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Finishing, Medium, Roughing
Insert Type Positive
Application Ramp Milling, Slot Milling, Face Milling, Pocket Milling, Side Milling
Package Size 1
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Depth Of Cut Max 0.4100
Cutter Dia 2.0000 50.80MM
Insert Size Ic 11
Machine Side Connection Type Face Mill/Shell Mill
Tool Material Steel
Cut Dia Min 2.0000 50.80MM
Flutes/Inserts 3
Machine Side Connection Size 0.7500 19.05MM
Overall Len 1.5700 39.88MM
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Square
Max Ramp Angle 2.00°
Insert Style SH
Coolant Thru No
