Picture of INGERSOLL 2J1X-15R01 Milling Cutter 90.0° 1.500 Shell Arbor 0.5000 4 Flute 0.5 Max DOC 1.570 OAL

INGERSOLL 2J1X-15R01 Milling Cutter 90.0° 1.500 Shell Arbor 0.5000 4 Flute 0.5 Max DOC 1.570 OAL

ANSI: 2J1X-15R01

ISO: 2J1X-15R01

Need Assistance or Service? Please call 262-251-4020

Manufacturer: INGERSOLL
SKU: ING3024840
Delivery date: 3-5 days
$493.73

File Downloads

DXFSTPSTPL
Products specifications
Attribute name Attribute value
General Product Information
Insert Application Finishing, Semi Finishing, Roughing
Insert Type Positive
Application Face Milling, Side Milling, Pocket Milling, Ramp Milling, Slot Milling
Package Size 1
Made In USA No
Shipping State Illinois
Insert/Tool Tool
Dimensional Specifications
Cut Dia Min 1.5000 38.10MM - 1-1/2
Machine Side Connection Size 0.5000 12.70MM
Insert Size Ic 12
Flutes/Inserts 4
Machine Side Connection Type Face Mill/Shell Mill
Depth Of Cut Max 0.5000
Tool Material Steel
Overall Len 1.5700 39.88MM
Cutter Dia 1.5000 38.10MM - 1-1/2
Cutting & Machining Properties
Insert Shape/Cutter Pocket Shape Parallelogram
Insert Style AO
Coolant Thru No
Max Ramp Angle 3.70°
